Hikvision NEI-XM6425 2MP Modüler Yüz Tanıma - Analiz Mini Dome Network IP Kamera
1/2.8” Progressive Scan CMOS
1920 × 1080 @ 30fps
120dB WDR
3D DNR
H.265, H.265+, H.264, H.264+
Smart encoding: low bit rate, low latency
Audio in
Alarm I/O
ROI
Face capture by deep-learning technology
6 behavior analyses, 3 exception detection, andface detection
Built-in Micro SD / SDHC / SDXC card slot, up to128GB
Specifications Camera
Image Sensor
1/2.8" Progressive Scan CMOS
Min. Illumination
Color: 0.001 Lux @ (F1.2, AGC ON), 0.002 Lux @ (F1.6, AGC ON)
B/W: 0.0007 Lux@(F1.2, AGC ON), 0.001 Lux@(F1.6, AGC ON), 0 Lux with IR
Shutter Speed
Channel 1: 1/25 s to 1/100,000 s
Channel 2: 1 s to 1/100,000 s
Slow Shutter
Yes (channel 2)
Auto-Iris
No
Day & Night
IR Cut Filter
Digital Noise Reduction
3D DNR
WDR
120 dB
Angle Adjustment
L80 IR Dome Lens: pan: -30 to 30, tilt: 0° to 75° (2 mm 0° to 60°), rotate: -180° to 180°
L90 IR Turret Lens: tilt: 0° to 75°, rotate: -180° to 180° Lens
Focal length
L32/L90: 2 mm/2.8 mm/4 mm
L80: 2 mm/2.8 mm/4 mm/6 mm/8 mm
Focus
No
FOV
L32/L90: 2 mm/2.8 mm/4 mm
2 mm @ F2.0: horizontal FOV 132.8°, vertical FOV 77.5°, diagonal FOV 153°
2.8 mm @ F1.6: horizontal FOV 110.5°, vertical FOV 60°, diagonal FOV 130°
4 mm @ F1.6: horizontal FOV 86°, vertical FOV 45°, diagonal FOV 102°
L80: 2 mm/2.8 mm/4 mm/6 mm/8 mm
2 mm @ F2.0: horizontal FOV 132.8°, vertical FOV 77.5°, diagonal FOV 153°
2.8 mm @ F1.6: horizontal FOV 110.5°, vertical FOV 60°, diagonal FOV 130°
4 mm @ F1.6: horizontal FOV 86°, vertical FOV 45°, diagonal FOV 102°
6 mm @ F1.6: horizontal FOV 52.7°, vertical FOV 30.3°, diagonal FOV 60.3°
8 mm @ F1.6: horizontal FOV 40.5°, vertical FOV 22.4°, diagonal FOV 46.8°
Aperture
F1.6, F2.0
Lens Mount
M12 IR
IR Range
L80/L90: 5 m
Wavelength
850 nm Compression Standard
Video Compression
Main stream: H.265/H.264
Sub-stream: H.265/H.264/MJPEG
H.265 Type
Main Profile
H.265+
Main stream support
H.264 Type
Baseline Profile/Main Profile/High Profile
H.264+
Main stream support
Video Bit Rate
32 Kbps to 16 Mbps
Audio Compression
G.711/G.722.1/G.726/MP2L2/PCM
Audio Bit Rate
64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)
SVC
H.264 and H.265 supportSmart Feature-set
Behavior Analysis
Channel 1: Line crossing detection, intrusion detection, region entrance, region exiting, unattended baggage, object removal
Channel 2: No
Exception Detection
Channel 1: Scene change detection, defocus detection, audio exception detection
Channel 2: No
Face Detection
Channel 1: Yes
Channel 2: No
Face Capture
Channel 1: Yes
Channel 2: No
Region of Interest
Channel 1: 4 fixed regions for each stream, and dynamic face tracking
Channel 2: No Image
Max. Resolution
1920 × 1080
Main Stream
50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720)
60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)
Sub Stream
50Hz: 25fps (704 × 576, 640 × 480)
60Hz: 30fps (704 × 480, 640 × 480)
Image Enhancement
BLC, HLC, 3D DNR, Defog, EIS
Image Settings
Rotate mode, saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser
Target Cropping
No
Day/Night Switch
Day/Night/Auto/Schedule/Triggered by Alarm in
Picture Overlay
LOGO picture can be overlaid on video with 128 × 128 24bit bmp format Network
Network Storage
Micro SD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR
Alarm Trigger
Motion detection, video tampering alarm, network disconnected, IP address conflict, illegal login, HDD full, HDD error
Protocols
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
General Function
One-key reset, anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
Firmware Version
V5.5.42
API
ONVIF (PROFILE S, PROFILE G), CGI, ISAPI
Simultaneous Live View
Up to 20 channels
User/Host
Up to 32 users
3 levels: Administrator, Operator and User
Client
iVMS-4200, iVMS-4500, iVMS-5200, Hik-Connect
Web Browser
IE8+, Chrome 41.0-44, Firefox 30.0-51, Safari 8.0-11 Interface
Audio
1 input (line in), 1 output (line out), mono sound
Alarm
2 inputs, 2 outputs (up to 12 VDC, 30mA)
Communication Interface
RS485, built-in RS232, 1 10M/100M Ethernet port
On-board storage
Built-in micro SD/SDHC/SDXC slot, up to 128 GB
Reset Button
Yes Audio
Environment Noise Filtering
Yes
Audio Sampling Rate
8kHz/16kHz/32kHz/44.1kHz/48kHz General
Available Model
Operating Conditions
-30 °C to 60 °C (-22 °F to 140 °F), humidity 5% to 95% or less (non-condensing)
Power Supply
8 VDC to 36 VDC, two-core aviation plug, aviation plug adapter cable to 3.5 mm power, M8 PoE (802.3at, class4)
Power Consumption and Current
24 VDC, 0.7 A, max. 15 W, 8-36 VDC
PoE (802.3at, 42.5 V to 57 V), 0.4 A to 0.3 A, max. 16 W
Protection Level
L80: IP66, IK10
L32: IP66 (2 mm: No)
Material
Metal
Dimensions
Main body: 135 × 107.8 ×30.4 mm (5.3" × 4.3" × 1.2")
Weight
Main body: approx. 450 g (1 lb.)
With package: approx. 920 g (2 lb.)
